Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz

1
MOQ
US$14,500 - 20,000
قیمت
Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
برجسته کردن:

four-slice stone cutting machine,granite marble edge cutter,quartz slab diamond wire saw

,

granite marble edge cutter

,

quartz slab diamond wire saw

اطلاعات اولیه
محل منبع: فوجیان ، چین
نام تجاری: Xianda
گواهی: API, CCC, SONCAP, GOST, ISO, CE
شماره مدل: HKB-41500
پرداخت
زمان تحویل: 45 روز
شرایط پرداخت: D/A، D/P، T/T، وسترن یونیون، L/C
قابلیت ارائه: 1000 مجموعه در سال
توضیحات محصول
Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz
Model HKB-41500 CNC Cutting Machine

High accuracy four-slice edge cutting machine for column slab processing with 10-20x efficiency over manual work.

Key Specifications
Attribute Value
Model HKB-41500
Type CNC Cutting Machine
Applications Concrete Curb, Granite, Marble
Max Processing Length 1500mm
Max Processing Width 1500mm
Cutting Angle 0-180°
Gross Power 35kw
Dimensions 4500×3600×2000mm
Weight 4500kg
Water Consumption 6m³/H
Certifications API, CCC, SONCAP, GOST, ISO, CE
Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz 0 Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz 1
Product Features
  • High-precision CNC control for accurate edge cutting
  • Specialized worktable design for column slab processing
  • 10-20 times more efficient than manual processing
  • Multi-functional for various stone materials
  • Robust construction for industrial applications
Technical Parameters
Parameter Unit HKB-41500
Max processing length mm 1500
Max processing width mm 1500
Cutting angle ° 0-180°
Gross power kw 35
Outline dimension mm 4500×3600×2000
Gross weight kg 4500
Water consumption m³/h 6
About Xianda Machinery

Fujian Xianda Machinery Co., Ltd is a leading manufacturer of stone cutting machines and tools, established in 1985 in Jinjiang, Fujian, China. With over 34 years of experience, we specialize in developing diamond wire saw machines, column processing machines, and bridge cutting machines.

We hold 80% of China's market share for column processing machines and serve customers in over 30 countries worldwide. Our company maintains "Top Technology and Superior Quality" as our standard, certified by CE and ISO Quality Gold Award.

Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz 2
Our Product Range
Our Services
  • Machine installation and operation training
  • Overseas engineer support for machinery service
  • 24-hour online after-sales service
  • One-year warranty on all machines
  • Technical support available anytime
Quality Assurance

Each machine undergoes strict inspection before shipping. We provide testing videos upon customer request and maintain comprehensive quality control throughout production.

Four-Slice Edge Stone Cutting Machine for Column Slab Granite Marble Quartz 9
Frequently Asked Questions
How to place an order?

1. Inquiry and professional quotation
2. Confirm price, lead time, and payment terms
3. Receive proforma invoice
4. Make deposit payment
5. Production begins after payment confirmation

What is the warranty period?

We provide one year parts warranty service for all machines.

What materials can this machine process?

This machine is designed for cutting columns, big arc-shaped slabs, and special stone shapes in materials including granite, marble, and quartz.
